M322E
    Publish time 2023-08-07 17:22
M322E
WTS  ModelM322EM322E.20M322E.40
Sensitivity80mv/g40mv/g20mv/g
Measurement Range±10 g pk±20 g pk±40 g pk
Frequency Range ±5%0-500Hz0-500Hz0-500Hz
Frequency Range ±10%0-800Hz0-800Hz0-800Hz
Noise  μg/√Hz7595110
Linearity≤0.1%≤0.1%≤0.1%
Horizontal Sensitivity≤3%≤3%≤3%
Operating Temp. Range-40~125℃-40~125℃-40~125℃
Sensing ElementMEMSMEMSMEMS
Output Voltage Range8~24 VDC8~24 VDC8~24 VDC
Supply Current≤1.1mA≤1.1mA≤1.1mA
Connector1/4-28 6-Pin1/4-28 6-Pin1/4-28 6-Pin
Insulation resistance ---
Case MaterialTitaniumTitaniumTitanium
Case sealingLaser weldingLaser weldingLaser welding
Weight11g11g11g
Size18X18X16 mm18X18X16 mm18X18X16 mm
Mounting 2-Φ4.1 Through hole2-Φ4.1 Through hole2-Φ4.1 Through hole
