D123E
    Publish time 2014-09-24 10:21
D123E
WTS  ModelD123ED123E.5D123E.6
Sensitivity10 mV/g50 mV/g100 mV/g
Measurement Range±500 g pk±100 g pk±50 g pk
Frequency Range (±5%）1~11k Hz1~11k Hz1~10k Hz
Frequency Range (±10%)0.5~12k Hz0.5~12k Hz0.5~11k Hz
Resonant Frequency>40K>37K>35K
Resolution0.001 g rms0.0002 g rms0.0001 g rms
Non-Linearity≤1%≤1%≤1%
Transverse Sensitivity≤5%≤5%≤5%
Operating Temp. Range-50 - +120 ℃-50 - +120 ℃-50 - +120 ℃
Sensing Element/GeometryCeramics/ShearCeramics/ShearCeramics/Shear
Output Tyle6-40 side6-40 side6-40 side
Electrical Isolation——————
Compliance Voltage18~30 VDC18~30 VDC18~30 VDC
Current range2~10 mA2~10 mA2~10 mA
Output Bias Voltage8-12V8-12V8-12V
Output Impedance≤100 Ω≤100 Ω≤100 Ω
Case MaterialTitaniumTitaniumTitanium
Case sealingLaser weldingLaser weldingLaser welding
Weight1.3g1.5g1.9g
Size8.5x5.1mm8.5x5.1mm8.5x5.1mm
Mounting AdhesiveAdhesiveAdhesive
