X311E
    Publish time 2023-08-07 15:02
X311E
WTS  ModelX311EX311E.2X311E.5X311E.6
Sensitivity10 mV/g20 mV/g50 mV/g100 mV/g
Measurement Range±500 g pk±250 g pk±100 g pk±50 g pk
Frequency Range (±5%）1~10k Hz1~10k Hz1~10k Hz1~10k Hz
Frequency Range (±10%）0.5~11k Hz0.5~11k Hz0.5~11k Hz0.5~11k Hz
Resonant Frequency>78K>38K>38K>38K
Resolution0.001 g rms0.0005 g rms0.0002 g rms0.0001 g rms
Non-Linearity≤1%≤1%≤1%≤1%
Transverse Sensitivity≤5%≤5%≤5%≤5%
Operating Temp. Range-50 - +120 ℃-50 - +120 ℃-50 - +120 ℃-50 - +120 ℃
Sensing Element/GeometryCeramics/ShearCeramics/ShearCeramics/ShearCeramics/Shear
Output Tyle1/4-28 4-pin1/4-28 4-pin1/4-28 4-pin1/4-28 4-pin
Electrical Isolation————————
Compliance Voltage18~30 VDC18~30 VDC18~30 VDC18~30 VDC
Current range2~20 mA2~20 mA2~20 mA2~20 mA
Output Bias Voltage9-11V9-11V9-11V9-11V
Output Impedance≤100 Ω≤100 Ω≤100 Ω≤100 Ω
Case MaterialTitaniumTitaniumTitaniumTitanium
Case sealingLaser weldingLaser weldingLaser weldingLaser welding
Weight4.3g4.6g8.4g8.4g
Size10.2 mm Cube10.2 mm Cube11.5 mm Cube11.5 mm Cube
Mounting 5-40 Screw hole  5-40 Screw hole  5-40 Screw hole  5-40 Screw hole
